Installation
Connection to mains supply
 Insert the mains power cable into socket and connect it to a wall socket
CAUTION: Do not place the device in a location where the power cord could be tripped over or pulled out during treatment.
Do not connect this device to any wall outlet that has not been properly grounded, or to any electrically non-isolated medical
device.
Use only ACP specified accessories and/or supplies with ACP devices. Do not use any power cords, or power supplies, other
than the ones provided or specified for this device. Use of any other power supply could seriously damage the device and will
void the warranty.
 Turn on the power line switch located above the power cord inlet.
 Power LED indicator is lit green indicating that the device is connected to the mains supply.
 Turn on the device with the orange push button located at the top of the unit next to the USB port.
 The device will initialize and perform a self-test. Allow the device a minute or so to start up.
 At the end of the self-test the device enters the Home menu and is ready for use.
Disconnection from mains supply
 Turn off the device with orange push button located at the top of the device next to the USB port.
 Power indicator LED is still lit green, indicating that the device is still connected to the mains supply and that the
battery is being charged.
 Set power line switch located above the power cord to “OFF” to stop charging and to disconnect the unit from
the mains supply.
Installing/Replacing the battery
 Remove the power cable from the power line inlet.
 Turn the device upside down and on a soft surface.
 Remove the two screws from the battery cover using the supplied screwdriver.
 Slide and lift the battery cover.
 Align the battery on the bottom of the main unit with the polarity of battery terminals in the correct position. The
polarity is marked at the bottom of the battery compartment.
 Locate the black wire and attach it to the – terminal of the battery.
CAUTION: Do not interchange the black and red wires as this will damage your device. The battery contains material that
is noxious to the environment. Observe the local regulations when disposing of the battery.
 Locate the red wire and attach it to the + terminal of the battery.
 Slide the battery upside down into the battery compartment taking care that the wires do not get jammed.
 Place and slide the battery cover back into position.
 Secure the battery cover with the two screws using the supplied screwdriver.
 Place the device back on its feet.
 Reconnect the mains cable to the power line connector.
Operation from battery
 Charging: Plug in power cord. Turn ON the Power Switch (back of unit). Power LED indicator will turn green
while charging. Turning orange push button ON or OFF does not affect charging.
 Operation: Push orange button to turn ON display.
 ON/OFF: To turn the device OFF in between therapy sessions, push orange button to turn OFF.
 Battery Life: Battery charge status is indicated in the right hand top corner of the display.
Recommendation: Keep device in charging mode when possible. This will increase the service life of the battery.
