- 100 - OMNIVERSA
®
MULTI-MODALITY THERAPY USER MANUAL
COPYRIGHT © 2017-2020, ACCELERATED CARE PLUS CORP., ALL RIGHTS RESERVED
TECHNICAL SPECIFICATIONS
GENERAL:
Dimensions (W x H x D): 10” (24cm) x 5” (12cm) x 12.5” (32cm)
Weight (including battery): 6lbs 10oz (3Kg)
Operating Power: 100 - 240VAC; 50/60Hz; 100 VA
System Memory:
The system remembers all prior custom settings from treatment to treatment as it is stored to
memory.
System Architecture: CMOS integrated micro-controller with on board memory and instruction set.
ENVIRONMENTAL CONDITIONS (STORAGE AND TRANSPORTATION):
Temperature -20° to +70° C
Relative humidity 10 to 90 % (contained in original packaging)
Atmospheric pressure 500 to 1060hPa
ENVIRONMENTAL CONDITIONS (NORMAL OPERATION):
Temperature 10° to 40° C
Relative humidity 10 to 90 % non-condensing
Atmospheric pressure 500 to 1060hPa
STIMULATION SYSTEM:
Output:
Constant voltage (CV) above 1000 ohms, the system then operates in constant current with
impedances less than 1000 ohms.
Output/Waveform:
AC square wave into resistive load, IFC and MFAC modes, and biphasic asymmetrical or
symmetrical square wave (LVPC) or mono-phasic pulsed current (HVPC mode). Output
Amplitude: IFC 0 to 100 mA RMS current into a 500Ω, LVPC mode 140mA P-P, HVPC mode
225VDC peak into 500Ω loads.
Channel Isolation: Independent transformer isolation.
Line Leakage: <50 µA on line power
MFAC (MEDIUM FREQUENCY ALTERNATING CURRENT) MODE:
Output/Waveform:
0 – 100 mA peak, 500 Ω load; square wave into resistive load 2 KHz, 2.5 KHz,3 KHz, 3.5 KHz, 4
KHz, 5 KHz , 6 KHz, 7 KHz, 8 KHz, 9 KHz, and 10 KHz carrier frequency.
Burst Rate: Adjustable from 0.1 to 200 bps, 50% duty factor
Rate Scan: From 0-50%, from 0-20 seconds
LVPC (LOW VOLTAGE PULSED CURRENT) MODE:
Output/Waveform: 0 – 140 mA peak, 500 Ω load; Asymmetrical biphasic square wave
Phase Duration: 10 - 300 µs
Pulse Rate: 1 – 200 Hz
IFC (INTERFERENTIAL CURRENT) MODE:
Output/Waveform: 0 – 100 mA peak, 500 Ω load; Full Field IFC (Premodulated)
Frequency Difference Rate:
Output channel A, fixed at 2.0 KHz, 2.5, KHz, 3.0 KHz, 3.3 KHz, 4.0 KHz, or 5.0 KHz. Output
channel B variable from channel A frequency + .0 to 250 Hz. Beat rate may be set during
treatment.
Full Field Burst Rate: 0.1 – 200 Hz
Rate Scan:
0-20 seconds, 0-50% modulation. Upper and lower frequencies are fully programmable and
sweep time is adjustable in set mode.
