PENS SKATE
This protocol simulates skating and can be used for lower extremity neuromuscular re-education in a lateral
(side to side) movement pattern.
Positioning – Early rehab: Have athlete lie on training table with hips and knees flexed, or legs over table.
Positioning – Mid to Late Rehab: Have athlete stand on a slide board with hip and knees slightly bent while they
wt, shift, or mimic skating motion across slide board with stim.
Positioning – Mid rehab: Have athlete stand on a slide board with hip and knees slightly bent weight shift with
stim.
Intensity: Moderate to strong muscle twitch with active muscle contraction. Adjust amplitude during the
treatment in response to the electrical stimulation, when and as needed
User
Adjustable
Parameter
(Y/N)
Parameter Name
Adjustable
Range (unit) Default (unit)
Y PHASE DURATION 40…100 (μs) 70 (μs)
Y CYCLE TIME .5 – 6 sec 1.3(s)
N PULSE RATE 100-50 Hz 50 (Hz)
Y TREATMENT TIME 0…60 (min) 15 (min)
PENS JUMP
This protocol simulates jumping and provides aggressive neuromuscular re-education of the lower extremities.
Positioning: Standing with both knees slightly flexed. Instruct the athlete to actively jump when they hear the
tone, in synchrony with the start of the electrically stimulated muscle contractions.
Intensity: Moderate to strong muscle twitch with active muscle contraction. Adjust amplitude during the treatment
in response to the electrical stimulation, when and as needed.
User
Adjustable
Parameter
(Y/N)
Parameter Name
Adjustable
Range (unit) Default (unit)
Y PHASE DURATION 40…100 (μs) 70 (μs)
N CYCLE TIME 15 (s) 15 (s)
N PULSE RATE 10-100 Hz 50 (Hz)
Y* REPEAT CYCLE 0…99 12
N TREATMENT TIME 0…60 (min) 15 (min)
N T-ON 0…30 (s) 1 (s)
1
N T-OFF 0…199 (s) 14 (s)
1
* Repeat Cycles are adjustable on Indications mode only
