AR-B1479 User’s Guide
37
Clear NVRAM
This sets the operating mode of the boot block area of the BIOS FLASH ROM to allow programming in the Yes
setting.
PCI Latency Timer (PCI Clocks)
This option sets latency of all PCI devices on the PCI bus. The settings are in units equal to PCI clocks.
PCI IDE BusMaster
Enabled this option is to specify that the IDE controller on the PCI local bus has bus mastering capability.
DMA & IRQ
These options specify the bus that the named IRQs/DMAs lines are used on. These options allow you to specify
IRQs/DMAs for use by legacy ISA adapter cards. These options determine if the BIOS should remove an
IRQ/DMA from the pool of available IRQs/DMAs passed to BIOS configurable devices. If more IRQs/DMAs must
be removed from the pool, the end user can use these PCI/PnP Setup options to remove the IRQ/DMA by
assigning the option to the ISA/EISA setting. Onboard I/O is configurable by BIOS.
Reserved memory Size
This option specifies the size of the memory area reserved for legacy ISA adapter cards.
Reserved memory Address
This option specifies the beginning address (in hex) of the reserved memory area. The specified ROM memory
area is reserved for use by legacy ISA adapter cards.
5.7 PERIPHERAL SETUP
This section is used to configure peripheral features.
AMIBIOS SETUP - PERIPHERAL SETUP
(C) 1998 American Megatrends, Inc. All Rights Reserved
OnBoard FDC Auto
Parallel Port DMA Channel N/A
OnBoard PCI IDE Enabled
Primary Master Prefetch Enabled
Primary Slave Prefetch Enabled
Available Options :
Auto
Disabled
Enabled
ESC:Exit ↑↓:Sel
PgUp/PgDn:Modify
F2/F3:Color
Figure 0-9 BIOS: Peripheral Setup
OnBoard FDC
This option enables the floppy drive controller on the AR-B1479.
OnBoard Serial Port
This option enables the serial port on the AR-B1479.
OnBoard Parallel Port
This option enables the parallel port on the AR-B1479.
Parallel Port Mode
This option specifies the parallel port mode. ECP and EPP are both bi-directional data transfer schemes that
adhere to the IEEE 284 specifications.
