ACT1000/2000 Operating Instructions Software Version 4.00-00
17
TIMERS
The door timers menu allows the installer to program the time delays for the relay, AUX output,
open collector outputs OP2 and OP3 and the door ajar alarm time. Each timer may be programmed
with a duration from 1 to 999 seconds. The relay time may be programmed to 0 seconds, which
will operate the relay for a quarter of a second approximately. This can be used for turnstile
applications. Door Stations will support a maximum duration of 127 seconds.
Timed Actions
This Menu allows the user to set up a number of actions that will occur at requested times. The
time that a particular action should occur is set up in a timezone and then assigned to that action.
When the time timezone is in force, then the assigned action occurs for that duration.
Action What Happens
Unlock Door For the duration of the assigned timezone, the door remains unlocked. The
Green LED on the Reader will Flash
Lock Door For the duration of the assigned timezone, the door remains locked. The Red
LED on the Reader will Flash.
PIN Required For the duration of the assigned timezone, a valid PIN code must be entered
after any card is presented. This overrides any PIN required option that may
be set for any group or user.
Any Card For the duration of the assigned timezone, any card presented will be
granted access as long as it contains Track 2 data, even if it would not
normally be granted access.
Activate OP2 For the duration of the programmed timezone, the user programmable
output OP2 is active.
Activate OP3 For the duration of the programmed timezone, the user programmable
output OP3 is active.
Activate AUX For the duration of the programmed timezone, the 1A auxiliary relay
output AUX is active.
PIN Only For the duration of the programmed timezone, the reader is disabled, and
access is granted only by entering a valid PIN.
PIN or Card For the duration of the programmed timezone, either a valid PIN or a valid
Card will allow access.
Communications
This menu allows the installer to configure how the controller communicates with externally
connected devices or over a network. It is used primarily to configure the communications mode
or address of the unit, or to specify log printer options.
SET ADDRESS
This option allows the address of the controller to be set when it is operating in a networked
system or when directly connected to a PC. The valid address may be from 1 to 255 and
corresponds to the number of the controller as configured in ACTWinPro.
DIRECT CONN.
This option informs the controller that it is connected directly to a controlling PC, rather than via
a network interface. In this mode of operation, only a single controller may be connected to the
PC via a cable (max 30m) from one of the PC serial ports.
