ACT1000/2000 Operating Instructions Software Version 4.00-00
1
Text Entry
Textual descriptions (user names etc.) are entered via a simple text entry system. Each of the digits
1-9 may be used to enter letters, numbers or symbols according to the table below. Pressing the
required digit once will bring up the first letter in that group. Subsequent presses will step through
the group and then back to the first letter. Pressing the 0 key advances to the next character and
pressing the ✘ key moves back to the previous character. The ✔ key accepts the currently
displayed text. If the cursor is at the first location in the display, pressing the ✘ key gives the
option to cancel all the displayed text.
Operating Instructions for
ACT1000/2000 Access Control Units
Software Version: 4.00-00
All user functions are accessed via two six-digit codes. The first code is for the Operator who is
responsible for the day-to-day administration of the system, adding and deleting users, setting
names and assigning time-zones etc. The second code is for the Installer who performs the initial
configuration of the system and decides on communications settings, interfaces, and modes of
operation.
Default Codes
Operator 123456 Installer 999999
Menu System
All user functions are accessed via a menu system. The menu (or submenu) title appears on the
top line of the display. The bottom line contains the current item in the menu. The three keys on
the bottom row of the keypad are used for navigation:
Menu Navigation Keys
✘ Quit to previous menu Next menu item ✔ Select item or Submenu
Text Entry Keys
1a b c A B C 1 2 d e f D E F 2 3 g h i G H I 3
4j k l J K L 4 5 m n o M N O 5 6 p q r P Q R 6
7s t u v S T U V 7 8 w x y z W X Y Z 8 9 SPC - & . + ‘ / 9 0
✘ Previous Character 0 Next Character ✔ Accept displayed text
