Acteon Mini LED - Buttons; Wave peak

7.5 Buttons
The Mini LED has two buttons.
located near the optical guide used to switch the Mini LED on and off.
used to select the required operating mode.
7.6 Wave peak
The waveform and its peak are identical in all three operating modes.
Opalescent optical guide
Amber-coloured optical
guide
Wave peak 447.5 nm 447.5 nm
Maximum irradiance at 2 mm 1900 mW / cm
2
1300 mW / cm
2
Mean spectral irradiance in relation to the nominal value and
over time
1,250 mW / cm
2
925 mW / cm
2
Page 18/38 - User Manual | Mini LED™ | J02541|V8|(07)| 01/2017|NG13EN010H
