24
Actiontec DSL Modem User Manual
Total Available Bandwidth
Displays the total amount of available bandwidth (in kilobits per second).
High Priority Bandwidth
Enter the amount of high priority bandwidth to be used by the prioritized
traffic type (cannot exceed total available bandwidth).
Priority
Always set to “High” and cannot be changed.
Protocol
Select the data type being configured. Options: TCP, UDP, ICMP.
Source
Identify the source device here, using the device’s IP or MAC address, then enter
appropriate value in text box. If IP is used, enter the netmask address, if applicable.
A priority port range can also be defined, using the “Port Range” text boxes.
Destination
Identify the destination device here, using the device’s IP address, then enter appro-
priate value in text box. Enter the netmask address, if applicable. A priority port
range can also be defined, using the “Port Range” text boxes.
Rule List
After finishing the configuration of the QoS settings, click Add to save the settings
in the Rule List menu box. This collection of QoS settings can then be reused at a
future time. If deleting a QoS rule list, highlight it, then click Remove.
When finished in this screen, click Apply to activate any changes made.
