ActionTec GT701D User Manual

5
Chapter 1 Introduction
Reset Switch
Depressing the Reset switch restores the Modem’s factory default settings. To
reset the Modem, depress and hold the Reset switch for five to seven seconds.
The reset process will start after releasing the switch, during which the Power
light will turn from green to orange.
USB Port
The USB port is used to connect a computer to the Modem via USB cable.
Power Port
The Power port is used to connect the Power cord to the Modem.
M
Warning: Do not unplug the Power cord from the Modem dur-
ing the reset process. Doing so may result in permanent damage
to the Modem.
Power Switch
The Power switch is used to power the Modem on and off.

ActionTec GT701D Specifications

General

Compliance industry standards	ANSI T1.413 Issue 2, ITUG.992.1 (G.dmt) & G.992.2 (G.lite)
DC-in jack	Yes
Modem (RJ-11) ports	1
Connectivity LEDs	3
Compatible operating systems	Microsoft XP, Vista; Mac OS 9+; Linux/BSD, Unix
