Description
Digital / Inverter Classic II Type Modbus Register Read/Write UoM Min Max
Compressor 1 Status
Compressor 1 running status
(0=Off, 1=On)
l
l
Analog 1101 R 1 0 1
Compressor 1 Heating (0=Off, 1=On)
l
l
Analog 1102 R 1 0 1
Compressor 1 Demand (0.1%)
l
l
Analog 1104 R 0.1% 0.0% 100.0%
Compressor 1 Speed (0.1%)
l
Analog 1105 R 0.1% 0.0% 100.0%
Compressor 1 Unit Defrosting
(0 = Off, 1 = Defrosting)
l
l
Analog 1107 R 1 0 1
Compressor 1 Suction Pressure (kPa)
l
Analog 1111 R 1kPa 0kPa 6000kPa
Compressor 1 Discharge Pressure (kPa)
l
Analog 1112 R 1kPa 0kPa 6000kPa
Compressor 1 Suction Temperature (0.1°C)
l
Analog 1113 R 0.1°C -999.9°C 999.9°C
Compressor 1 Discharge Temperature
(0.1°C)
l
Analog 1114 R 0.1°C -999.9°C 999.9°C
Compressor 1 Suction Superheat (0.1°K)
l
Analog 1115 R 0.1°K -99.9°K 99.9°K
Compressor 1 Suction Superheat Target
(0.1°K)
l
Analog 1117 R 0.1°K -99.9°K 99.9°K
Compressor 1 LP Switch Trip (0=Off, 1=Trip)
l
l
Analog 1118 R 1 0 1
Compressor 1 HP Switch Trip (0=Off, 1=Trip)
l
l
Analog 1119 R 1 0 1
Compressor 1 HP or LP Lockout
(0=Off, 1=Lockout)
l
l
Analog 1122 R 1 0 1
OD Coil
Outdoor Coil 1 Temperature (0.1°C)
l
l
Analog 1201 R 0.1°C -99.9°C 99.9°C
Outdoor Coil 1 Fan Speed Setting
(0=Off, 1=Low, 2=Med, 3=High)
l
l
Analog 1215 R 1 0 3
ID Coil
Indoor Coil Temperature (0.1°C)
l
l
Analog 1301 R 0.1°C -99.9°C 99.9°C
Indoor Coil 1 Fan 1 Speed (0.1%)
l
l
Analog 1311 R 0.1% 0.0% 100.0%
Indoor Coil 1 Fan 1 Speed (RPM)
l
l
Analog 1312 R 1RPM 0RPM 9999RPM
EEV
Compressor 1 EEV position (0.1%)
l
Analog 1401 R 0.1% 0.0% 100.0%
Compressor 1 Discharge Temp High
(0=Off, 1=On)
l
Analog 1502 R 1 0 1
Compressor 1 LP Status
(0 = OK, 1 = Error)
l
Analog 1503 R 1 0 1
Compressor 1 HP Status
(0 = OK, 1 = Error)
l
Analog 1504 R 1 0 1
Compressor 1 Suction Temperature Status
(0 = OK, 1 = Error)
l
Analog 1505 R 1 0 1
Compressor 1 Discharge Temperature
Status (0 = OK, 1 = Error)
l
Analog 1506 R 1 0 1
Outdoor Coil 1 Temperature Status
(0 = OK, 1 = Error)
l
l
Analog 1507 R 1 0 1
Indoor Coil Temperature Status
(0 = OK, 1 = Error)
l
l
Analog 1508 R 1 0 1
