EN • 19
ENGLISHFRANCAISNEDERLANDSESpAñoLITALIANoDEuTSCH
664Y0200.C
BURNER MAINTENANCE [fig. 22]
1. After dismantling the burner, check the condition of the
ignition electrode (1) and ionisation electrode (2), the
insulation (3) and the burner chamber plate seal (4). Replace
these items if necessary.
2. Check the condition of the tube (5).
3. Re-assemble the burner and check burner ignition.
4. Check the gas connection for leaks.
5. Check the combustion parameters.
fig. 19
C
fig. 17
A
fig. 21
E
fig. 22
2
3
5
1
4
fig. 18
B
fig. 20
D
BuRNER CHARACTERISTICS
