MOUNTING YOUR AD NOTAM
ON WALL MOUNTING FINAL ASSEMBLY
Your own ad notam has been pre-assembled according to your configuration instruction. The product back view including pre-
assembled items is visible on your
shop drawing Page 3 (Back View)
you can find additional information on the visible items on
page 4 (Legend - Back View).
The product Wall View is visible on
shop drawing
page 5 (Wall View)
. Consult your
shop drawing
page 6 (Legend - Wall View)
for additional information concerning spare parts necessary for installation. Refer to these pages
during installation.
EXPERT TIPS TOOLS
