5.3 SETTING THE PRINTING PARAMETERS
When “F3 SEr” is displayed, press [Zero] to view the first printing
parameter.
5.3.1 Selecting the communication port
 The selected port, for example “S 232” will be displayed.
 Press [Mode] to cycle through the other options. The user
can select “S 232” or “S USb” as the communication port.
Currently, only RS-232 interface is available and the scale is
set with this port only.
 Press [Zero], to view the next printing parameter.
5.3.2 Setting the print mode
 The current setting of the print mode is displayed,
 Press [Mode] to cycle through the other options.
 The following options are available:
P1 Prt
The scale sends the accumulated weights to the
communication port, whenever the [Print] key is pressed.
P2 Con
It will set the RS-232 interface to print the weights
continuously and the accumulation function is disabled.
P3 AUT
The weighing results will be sent to the communication port
automatically whenever a weight is placed on the platform.
 Press [Zero], to view the next printing parameter.
5.3.3 Setting the baud rate
 The current baud rate setting will be displayed.
 Press [Mode] to cycle through the other options.
 The following settings are available:
b 600
b 1200
b 2400
b 4800 (default value)
b 9600
