6.0 CALIBRATION
 This parameter allows the user to calibrate the scale any
time during the operation.
 Switch the scale off and then on it again by pressing
[On/Off]. During the self-test press [Smpl] and [Print]
together.
 Display will show "unLoAd". Remove all weights from the
pan.
 Wait for the stability indicator to be on and then press [Zero].
 The display will then show the first calibration weight request.
 Press [Mode] to scroll through the other calibration weights.
 Press [Zero] to select calibration weight. The display will
show “LoAd”.
 Place this weight on the platform and press [Zero] when the
stability indicator will be on to show the value is stable.
 If the calibration is complete, the scale will show “PASS” and
will return to normal weighing counting back to zero. Remove
the calibration weight at this stage.
 If the wrong calibration weight is used, the scale will show
“FAlL H” (when the weight is higher) or “FAlL L” (when the
weight is lower). Repeat the process using the correct
calibration weight.
Calibration weights:
Model #
ACBplus
150
ACBplus
300
ACBplus
600
ACBplus
600H
ACBplus
1000
ACBplus
1500
ACBplus
3000
ACBplus
5000
Weight 1 50g 100g 200g 200g 500g 500g 1000g 2000 g
Weight 2 100g 200g 400g 400g 1000g 1000g 2000g 5000 g
Weight 3 150g 300g 600g 600g - 1500g 3000g -
7.0 COMMUNICATION WITH A COMPUTER/PRINTER
The ACBplus series of scales come with a standard RS-232 interface.
The standard Interface parameters are: Connection details are:
RS-232 output of weighing data
ASCII code
4800 Baud
8 data bits
No Parity
Connector: 9 pin d-subminiature socket
Pin 3 Output
Pin 2 Input
Pin 5 Signal Ground
