Total from Accumulation memory:
* * * * * * * * * * * * * * <cr><lf>
n = n n n n <cr><lf>
t o t a l = w w w w w w K G <cr><lf>
<lf>
<lf>
<lf>
<lf>
I.e.
* * * * * * * * * * * * * * <cr><lf>
n = _ _ _ 6 <cr><lf>
t o t a l = _ _ 6 2 , 5 K G <cr><lf>
<lf>
<lf>
<lf>
<lf
10.0 LOAD CELL CONNECTION
Load cell supply voltage: 5 VDC
Pin 1-2: +E Load cell excitation positive
Pin 4-5: -E Load cell excitation negative
Pin 7: +S Load cell output positive
Pin 8: -S Load cell output positive
Pin 3: GND Load cell cable shield
