Setting up the configuration
The desk can be set up with a number of different parameters, depending on the current
requirements of the operator. These parameters are :
• Writing to and from the memory card
• The patching of desk outputs to dimmer inputs
• Deleting memories
• Single or dual preset
• Setting the Effect section chase patterns
• Accessing the HELP text
• Remaining / free memories
• The contrast of the display
• Resetting the desk (Cold Booting or Cold Start)
• Working with submasters
The configuration dialogue for the desk is entered by pressing the «MENU» key. At this point the
display changes to offer a range of options which may be either accepted or modified as required.
If at any point a QUIT or SAVE key is pressed the configuration menu is exited and the display
returns to normal.
To change two or more parameters the «MENU» key must be pressed again to re-enter the
configuration mode. Pressing the "MENU" button at any time whilst in the configuration menu's
will exit at that point and ignore any modification made.
The first press of the "MENU" key gives the opening menu screen. Each option is adjacent to
one for the «NEXT» and «LAST» keys. Pressing the corresponding key either changes the
setting, or offers another menu screen from which further options are available. Figure 1 shows
the sequence of options and screens that makes up the full configuration options. The patching
of the DMX outputs is a slightly more complex procedure which is covered in detail in the
Patching the DMX output section of this manual.
MENU
