Page 30
Revision : 003
TANGO
Lighting Technologies
Controls, Indicators and Connectors
I d. Description
1 POWER input socket
2 DMX512/1990 output connector
(5 pin female 'D' type XLR)
3 REMOTE socket ( 9 pin female DB connector)
4 Analogue output connectors channels 1 / 24
5 Analogue output connectors channels 25 / 48
6 SERIAL No
7 Preset A manual faders
8 Preset A LED indicators
9 Preset A Flash buttons
10 Preset B manual faders
11 Preset B LED indicators
12 Preset B Flash buttons
13 Manual section TIMER fader
14 Preset A RUN LED
15 Preset B RUN LED
16 Preset A ON/OFF LED
17 Preset B ON/OFF LED
18 Preset A ON/OFF button
19 Preset B ON/OFF button
20 Preset A section fader
21 Preset B section fader
22 Memory PRESET NEXT and LAST buttons
23 LCD backlit display
24 Memory RECORD NEXT and LAST buttons
25 MENU configuration set-up entry button
I d. Description
26 AUX button with LED (for submaster mode)
27 Memory section ON/OFF button with LED
28 Memory section cross-fade RUN LED
29 Memory section MANUAL fader
30 Memory section MANUAL LED
31 Memory section STOP button
32 Memory section START button
33 MEMORY PREVIEW button
34 Memory MODIFY button
35 Memory TIME button
36 Memory INSERT button
37 Memory RECORD button
38 Effect's section ON/OFF LED
39 Effect's section ON/OFF button
40 Effect's section cross-fade RUN LED
41 Effect's section SPEED fader
42 Effect's section LEVEL fader
43 Effect's section Direction indicator LEDS
44 Effect's section DIRECTION button
45 Effect's section MODE button
46 Effect's section CHANNELS button
47 Effect's section START/STEP button
(operation depends on position of SPEED fader)
48 Master section ON/OFF LED
49 Master section ON/OFF button
50 Desk output Master level fader
51 MEMORY CARD insertion point (below front panel)
