INTRODUCTION
General Description
The Kentrox D-SERV DSU/CSU is a low cost, intelligent, single port
T1 DSU/CSU that provides channelized connections to T1 or
Fractional T1 (FT1) services. The serial data signal can operate in
increments of 56 Kbit/s or 64 Kbit/s, up to the full band width of
1.536 Mbit/s. The network T1 signal is always 1.544 Mbit/s. The CSU
portion of the D-SERV DSU/CSU insures that the signal is compatible
in format and pulse density with T1 requirements. The D-SERV
DSU/CSU provides line protection from voltage spikes, surges and
line crossings coming from the public network. In addition, the
D-SERV DSU/CSU generates alarm signals and performs loop backs
to aid in the turn up and trouble-shooting of expensive T1 circuits.
The D-SERV family of products includes models:
78220 D-SERV DSU/CSU Stand-Alone Unit, -24 to -48 VDC, with
aV.35DataPort
78222 D-SERV DSU/CSU Stand-Alone Unit, 110 VAC, with a
V.35 Data Port
78240 D-SERV DSU/CSU Stand-Alone Unit, -24 to -48 VDC, with
an EIA-530 Data Port
78242 D-SERV DSU/CSU Stand-Alone Unit, 110 VAC, with an
EIA-530 Data Port
78210 D-SERV DSU/CSU Plug-In card, -24 to -48 VDC, with a
V.35 Data Port
78230 D-SERV DSU/CSU Plug-In card, -24 to -48 VDC, with an
EIA 530 Data Port
78260 D-SERV 12-slot high density mounting chassis
78255 D-SERV 2-unit rack mounting tray
Operator's Manual
1
