Network Port
Grounding Lug
1
8
Figure 21. Network Port Location (AC Powered Units)
Network Port
Grounding Lug
8
1
Figure 22. Network Port Location (DC Powered Units)
Figure 23. RJ48C Pin Designation
Operator's Manual
35
