3
INSTALLATION
Installation Check List
Installing D-SERV Stand-Alone Units
¤ Read Operator Manual thoroughly
¤ Select Site for installation
¤ Configure unit with the DIP switches
¤ Complete mechanical installation/mounting
¤ Connect power and ground
(-24 to -48 VDC and 110 VAC operation)
¤ Connect Alarm Relay (DC units only)
¤ Connect interface cables
Installing D-SERV Plug-In Units
¤ Read Operator Manual thoroughly
¤ Select Site for installation
¤ Install 12 slot High Density Mounting Chassis
¤ Install enough back panels in the chassis to service the
D-SERV Plug-Ins that are being installed
¤ Connect power and ground (-24 to -48 VDC only)
¤ Connect Alarm Relay
¤ Connect interface cables
¤ Configure units with the DIP switches
¤ Individually slide each D-SERV unit into a slot in the
chassis and secure with the large screws in the front cover
Operator's Manual
23
