500
1000
AdeleX-10
is a universal FPV model of an aircraft with vertical take-off and
landing, VTOL. Its main payload is a two-axis rotating servo pan&tilt (gimbal)
for any 19x19mm FPV camera.
Recommended video system: DJI FPV with Polar/Nebula Pro/O3 cameras,
Walksnail Avatar.
The main advantage of a VTOL aircraft is the combination of the advantages
of a quadcopter and an airplane. The aircraft is capable of taking off and
landing vertically on unprepared and limited-size platforms and at the same
time flying quickly in horizontal flight.
In airplane mode, AdeleX-10 consumes approximately three times less
energy than when hovering.
Main characteristics:
Empty weight (without battery):
850 g
Normal take-off weight:
1300 g
Wingspan:
1000 mm
Wing area:
12.5 sq. dm
Wing load:
114 g/sq. dm
Cruising speed:
70 km/h
Stall speed:
50 km/h
Maximum speed:
150 km/h
Maximum wind speed
at the ground during takeoff:
7 m/s
Power at NVM:
hovering:
370 W
cruise mode:
130 W
Cruising range,
at a consumption of
4500 mAh
(6S):
35-40 km
Ceiling in airplane mode,
not less than:
2000 m
Operating temperature range:
-15 +35 degrees C
Flight controller software:
Ardupilot, INAV
The aircraft is adapted to
hand luggage dimensions of
major airlines.
Recommended Electronics:
Airplane:
Pusher motor (1 pcs) :
Motor EMax 2807 1300kv,
1.
ESC 6s 30A, propeller Gemfan 7042.
Lifting motors (4 pcs):
Motor 2004 EMax 1600 kv,
2.
propeller Gemfan 5126-2.
ESC
4in1 6S, no less than 30A per channel,
3.
Servos
:
GH-S37D (EMax Es9051) 4pcs.
4.
Batteries:
Li-Ion 6s1p 21700 with a current output of at least 30A.
5.
Flight controller:
Matek H743, SpeedyBee F405 wing.
6.
Airspeed sensor:
Matek ASPD-4525.
7.
Pan&Tilt:
Tilt servo:
GH-S37D (EMax Es9051)- 1 pcs.
8.
Rotation servo:
DM-s0090d (270 degrees)- 1 pcs.
9.
FPV video system:
DJI, Walksnail Avatar.
10.
Radio control system:
TBS Crossfire, ELRS.
11.
Cooling fan:
5V 3010
12.
