D
Push the stabilizer
until stop
Tighten the screws on both
sides after installing the
stabilizer
Secure the wires from the
motors with ties to the arms
Connect the stabilizer servo
to the FC
via extension cables
D
Route all wires through
the center section cable channel
Holes for cable ties
After installing the stabilizer,
make sure that the lift screws
do not touch anything,
including the pushing
propeller
20
Fuselage 4
To Next Page
