F
Insert the spar into the hole in
the fuselage and push it in so
that it is located
symmetrically.
Make sure that there are no
obstacles in the path of
inserting the spar.
Remove the battery
compartment cover by
turning the latch 90 degrees
Place the wings on the
spar so that the distance
to the fuselage is 20-25
mm.
Install the freshly charged battery,
carefully securing it with a belt.
If necessary, move the battery to
correct alignment.
F
Insert the aileron servo
cable into the mating
part in the center
section, observing the
polarity
(see label upside)
Label
Secure the console
using the knob,
tightening it until it stops.
The right wing is
installed in the same
way as the left one.
ATTENTION! Avoid excessive efforts when assembling
the airplane to avoid damaging it!
24
Pre-flight preparation 1
