E
Battery 6s1p
21700
Cover
Battery strap
Spar
carbon square profile
6x6x500 mm
ATTENTION!
FOR ALL CHECKS OF ELECTRONICS INDOORS,
DUE TO ONBOARD BATTERY CONNECTION, ALL PROPELLERS
MUST BE REMOVED FROM THE MOTORS TO AVOID SERIOUS
INJURY AND EQUIPMENT DAMAGE
E
After installing the console on
the spar and connecting the
aileron, tighten the knob
Insert the aileron servo cable into
the mating part in the center
section, observing the polarity
21
General assembly
