KAOS 15 Channel Mode
Channel Value Function
1 PAN CONTINUOUS ROTATION
0 - 7 PAN MOVEMENT USING CH. 2
8 - 132 CLOCKWISE ROTATION FAST - SLOW
133 - 140 STOP
141 - 255 COUNTER CLOCKWISE SLOW - FAST
2 PAN MOVEMENT
0 - 255 PAN MOVEMENT 0° - 540°
3 0 - 255 TILT 1 MOVEMENT 60° - 150
4 0 - 255 TILT 2 MOVEMENT 60° - 150
5 0 - 255 TILT 3 MOVEMENT 60° - 150
6 0 - 255 RED 0% - 100%
7 0 - 255 GREEN 0% - 100%
8 0 - 255 BLUE 0% - 100%
9 0 - 255 WHITE 0% - 100%
10 SHOWS
0 - 7 OFF
8 - 23 SHOW 1
24 - 39 SHOW 2
40 - 55 SHOW 3
56 - 71 SHOW 4
72 - 87 SHOW 5
88 - 103 SHOW 6
104 - 119 SHOW 7
120 - 135 SHOW 8
136 - 151 SHOW 9
152 - 167 SHOW 10
168 - 183 SHOW 11
184 - 199 SHOW 12
200 - 215 SHOW 13
216 - 231 SHOW 14
232 - 247 SHOW 15
248 - 255 SOUND ACTIVE SHOW
KAOS 15 Channel Mode
Channel Value Function
11 SHOW SPEED/SOUND SENSITIVITY
0 - 255 SHOW SPEED SLOW - FAST
0 - 255 LEAST SENSITIVE - MOST SENSITIVE
12 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 RANDOM STROBE
248 - 255 OPEN
13 0 - 255 MASTER DIMMER 0% - 100%
14 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
15 RESET
0 - 69 NULL
79 - 79 BLACKOUT W/ PAN/TILT MOVEMENT
80 - 89 RESET ALL
100 - 255 NULL
