ADJ Vision Series - Installation Guidelines; Qualification, Electrical, and General Warnings; Rigging, Mounting, and Overhead Safety

16
INSTALLATION
DO NOT INSTALL THE PANEL IF YOU ARE NOT QUALIFIED TO DO SO!
INSTALLATION BY QUALIFIED TECHNICIANS ONLY!
INSTALLATIONS SHOULD BE CHECKED BY A QUALIFIED PERSON AT LEAST
ONCE A YEAR!
FLAMMABLE MATERIAL WARNING
Keep panel(s) a minimum of 5.0 feet (1.5m) away from ammable materials and/or
pyrotechnics.
ELECTRICAL CONNECTIONS
A qualied electrician should be used for all electrical connections and/or instal-
latons.
A MAXIMUM OF 20 PANELS may be suspended from each other in a vertical
column. There is no limit on the number of panels that may be installed in a single
horizontal row. Note that additional processing power may be necessary to oper-
ate larger quantities of panels.
USE CAUTION WHEN POWER LINKING PANELS OF DIFFERENT MODEL TYPES,
AS POWER CONSUMPTION CAN VARY WITH MODEL TYPE, AND MAY EXCEED
THE MAX POWER OUTPUT OF THIS PANEL. CONSULT THE SILK SCREEN FOR
MAX CURRENT RATING.
Input Power AC 100-240VAC, 50/60Hz, 16A Max
Output Power AC 100-240VAC, 50/60Hz, 14A Max
Max Power Consumption 170W Max, 68W Average
• WARNING! The safety and suitability of any lifting equipment, installation location/platform, anchor-
ing/rigging/mounting method and hardware, and electrical installation is the sole responsibility of the
installer.
• Panel(s) and all panel accessories and all anchoring/rigging/mounting hardware MUST be installed fol-
lowing all local, national, and country commercial electrical and construction codes and regulations.
• Before rigging/mounting a single panel or multiple interconnected panels to any metal truss/structure,
a professional equipment installer MUST be consulted to determine if the metal truss/structure or
surface is properly certied to safely hold the combined weight of the panels(s), clamps, cables, and
all accessories.
• Inspect metal truss/structure visually to ensure it does not ex and/or become deformed due to the
weight of the panel(s). Damage caused to panel(s) by mechanical stress is not covered by warranty.
• Panel(s) should be installed in areas outside walking paths, seating areas, and areas where unauthor-
ized personnel might reach the panel(s) by hand. Access under work area must be blocked.
• NEVER stand directly below the panel(s) when rigging, removing, or servicing.
• OVERHEAD RIGGING: Overhead xture installation must always be secured with a secondary safety
attachment, such as an appropriately rated safety cable. Overhead rigging requires extensive experi-
ence, including calculating working load limits, knowledge of the installation material being used, and
periodic safety inspection of all installation material and the xture itself, among other skills. If you lack
these qualications, do not attempt the installation yourself. Improper installation can result in bodily
injury and property damage.
