ADJ Vision Series - Technical Specifications; General & Mechanical Ratings; Optical & Power Supply Specs; Control Systems & Environmental Data

28
Specicationssubjecttochangewithoutanypriorwrittennotice.
TECHNICAL SPECIFICATIONS
GENERAL
Resolution
• VS2: 168(H) x 168(V)
• VS3: 128(H) x 128(V)
• VS5: 84(H) x 84(V)
Pixel Pitch:
• VS2: 2.97mm (0.12”)
• VS3: 3.91mm (0.15”)
• VS5: 5.95mm (0.23”)
LED Conguration: SMD212
Pixel Density:
• VS2: 112896 pixels/m
2
• VS3: 65536 pixels/m
2
• VS5: 28224 pixels/m
2
Size:
• 19.68” x 19.68” x 2.74”
• (500mm x 500mm x 69.6mm)
Module Quantity: 4
Weight: 17.0 lbs (7.7 kgs)
MECHANICAL RATINGS
Surface Flatness: Gap < 0.5mm
OPTICAL RATINGS
Brightness: 1000 cd/m
2
Viewing Angle: 160° / 140°
Viewing Distance:
• VS2: 3m
• VS3: 4m
• VS5: 6m
Gray Scale: > 14bits
Display Colors: 256
Contrast Ratio: 5000:1
Brightness Adjustment: 0~100%, 100 levels
POWER SUPPLY
Operation Power: 100~240V 50~60Hz
Max Power Consumption: 170W per panel
Average Power Consumption:
• VS2: 68W per panel
• VS3: 101W per panel
• VS5: 94W per panel
Power/Data Connections:
• Power In/Out
• Data In/Out
CONTROL SYSTEMS
Control Mode: Constant Current Driving
Frame Update Frequency: 50~75Hz
Scan Mode:
• VS2: 1/21 duty
• VS3: 1/16 duty
• VS5: 1/7 duty
Refresh Rate: 3840 Hz
Support Input: RJ45
Control Distance:
• Ethernet Cable < 120m
• Fiber Optoc > 120m
Support VGA Mode:
• 1024x768
• 1280x1024
• 1600x1200
• 1920x1280
Brightness Correction:
• Pixel
• Module
• Cabinet
ENVIRONMENTAL
Operating Temp: -20° ~ +40° C / -4° ~ +104° F
Operating Humidity: 10~90% RH, no condensation
Operating Life: 50,000 hours
MTBF: 5000 hours
Protection Level: IP20
Out of Control Rate: < 0.02%
Curve Angle: n/a
