Adtech ADTECH9 Series User Manual

ADTECH9 Series CNC Maintenance Manual
- 210 -
RS485 interface RJ45 network interface
12.2.8. USB memory connection interface (96 series XS10)
Standard USB memory (e.g. USB disk) interface;
12.2.9. PC USB communication interface (96 series XS11, 99 series X13)
Standard USB communication interface;
11.3 Electrical connection diagram
11.3.1. Symbol schematic diagram
TXD
RXD
NC
NC
NC
NC
NC
GND
5
9
4
8
3
7
2
6
1
NC
