ADTECH9 Series CNC Maintenance Manual
- 223 -
11.3.8. ET202A splitter wiring diagram
ET202A splitter function definition
Termina
l No.
Area Port Name Function
J31
OUT00-OUT09
OUT00 OUT00
J31 OUT01 OUT01
J31 OUT02 OUT02
J31 OUT03 OUT03
J31 OUT04 OUT04
J31 OUT05 OUT05
J31 OUT06 OUT06
J31 OUT07 OUT07
J31 OUT08 OUT08
