Total Access 600R User Interface Guide (UIG)
WAN IP Setup - Frame Relay IP Setup Instructions
(required if the Total Access 600R is to be used for Frame Relay IP Routing on the
WAN interface)
Step Action
1
From the Main Menu, select R
OUTER
, select C
ONFIG
, and then select
WAN.
2 Set the L2 P
ROTOCOL
to F
RAME RELAY.
3 Press Enter on the F
RAME
R
ELAY
[+] option.
4
Set the M
AINTENANCE
P
ROTOCOL
to A
NNEX
D, A
NNEX
A, LMI,
OR
S
TATIC
.
The M
AINTENANCE
P
ROTOCOL
should be set based on the Frame
Relay switch.
WAN IP Setup-Frame Relay IP Setup - Map DLCIs
Step Action
1
From the Main Menu, select R
OUTER
, select C
ONFIG
, and press Enter
on the
F
RAME
R
ELAY
[+]
option.
2
Press Enter on DLCI M
APPING
[+]. Right arrow one time to create an
entry.
3
Set
A
CTIVE
to
Y
ES
.
4
Set
DLCI
to the DLCI number.
5 Press Enter on the IP M
AP
[+].
6
Set
A
CTIVE
to
Y
ES
.
7
Set
IARP
to
N
O
.
8
Configure WAN IP information
• Far-End IP Address The far-end WAN IP address from the
Total Access 600R.
• Subnet Mask The subnet mask for this WAN link
• Local IP The local WAN IP address for the Total
Access 600R.
The other config items can be left at the defaults.
9 For NAT configuration, please see IP Routing with NAT.
10
Press <Esc> to return to main menu. Confirm all changes by pressing
"y" when prompted.
