RUN SCREEN - Allows the user to select what will be shown on the screen while the controller is in the RUN
mode. Like displaying temperature readings, water meter totals for a particular system or the conductivity
units of measure.
NOTE: When entering values for custom names use the numerical keys for numbers and the up / down
arrows to scroll through all the characters of a key board. Press the right arrow to advance the curser after
setting a desired value. Press the Help button to place the last entered character into the new cursor space
to speed up the process. The Help button will also jump advance through the characters.
5.1 Notepad
typically tested for reporting a service call. The Notepad items come with no names but when an individual
note is selected a menu for setting it appears.
NAME -
your own.
NUMBER - Set the number range.
UNITS - Set the units of measurement.
ALARMS - Set Hi/Low alarm points and how frequently
a new value is expected to be manually enter via the
History menu.
5.2 mA Inputs
NAME - Name the input.
UNITS - Set the units of measurement.
NUMBER - Set the number range.
5.3 pH Index
If the controller has the pH index option (must have pH control) user can select LSI or RSI indexing. The
controller will automatically set some Notepad entries for manually inputting needed data to perform the
calculation which will be displayed in the RUN screens.
5.4 Run Screen
This lets you customize various aspects of the RUN screen.
MAIN SCREEN - Customize what is displayed on the
RUN screen.
SCREENS SHOWN - Pick if the mA input & Aux Flow
>NOTEPAD SYS 1 NOTE 1<
NAME
NUMBER
UNITS
ALARMS
>mA INPUT 1 CUSTOMIZE<
NAME
UNITS
NUMBER
>RUN SCREEN<
MAIN SCREEN
SCREENS SHOWN
CYCLE TIME
COND UNITS
To Next Page
