Additional relay logic is available with up to 3 additional Activators and up to 4 Disablers allowing multiple
functions to activate the same relay and multiple functions to prevent the relay from coming on. There is
also a Daily Max amount of time that a relay can be on. If a relay is on for the max amount, it does not
let the relay come on anymore that day. (A 24-hour clock is used for the day with midnight being the start
of the day). The Delay setting is the amount of time a control function must come on before the relay will
point or alarm.
8.3 History
alarm delay period and the USB history save format.
INTERVAL - The amount of time between each history
time stamp for probe readings.
W/M HOUR - The time of day that the daily water
meter history cycle is to start.
ALARM DELAY - The amount of time an alarm has to
be on before it is recognized as an alarm.
SAVE FORMAT - The USB history save format.
8.4 Flow Switch
8.5 Contrast
This menu is used to adjust the contrast of the display.
8.6 Temperature Scale
This menu is used to select the type of temperature scale to display.
8.7 Network
The Network menu is used when a controller is being remotely communicated with either a local network
connection or over the internet on the Web Advantage server.
NETWORK - This menu is used for setting up the
remote WebAdvantage communications and is
covered in a separate manual.
http://www.advantagecontrols.com/downloads/pdf/M-WebAdvantage.pdf
>CONFIGURE HISTORY<
INTERVAL
W/M HOUR
ALARM DELAY
SAVE FORMAT
>CONFIGURE NETWORK<
IP ADDRESS HTTP REMOTE
IP MASK FTP
GATEWAY RESET
SERVER
HTTP LOCAL
