ADAM-4019 command codes against Input ranges table
Table 4-3 Input Range Code for ADAM-4015 and ADAM-4019
Command Code (Hex) Input Type Input Range
02 mV – 100 mA
03 mV – 500 mA
04 V – 1V
05 V – 2.5 V
08 V – 10 V
09 V – 5V
0D mV – 20 mA
0E Thermocouple, J 0 C to 760 C
0F Thermocouple, K 0 C to 1370 C
10 Thermocouple, T -100 C to 400 C
11 Thermocouple, E 0 C to 1000 C
12 Thermocouple, R 500 C to 1750 C
13 Thermocouple, S 500 C to 1750 C
14 Thermocouple, B 500 C to 1800 C
