Technical specifications
A-16 ADAM 4000 Series User's Manual
A.7 ADAM-4017, 4017+ 8-Channel Analog Input Module
Table A-9 ADAM-4017 Specifications
Analog input channels Six differential
Two single-ended
Input type mV, V, and mA
Input range ±150 mV, ±500mV,
±1 V, ±5 V, ±10 V and ±20mA
Output RS-485 (2-wire)
speed (bps) 1200, 2400, 4800, 9600, 19.2K, 38.4K
maximum distance 4000 ft. (1200 m)
Isolation voltage 3000 V
DC
Sampling rate 10 samples/sec(total)
Bandwidth 13.1 Hz
Accuracy ±0.1% or better
Zero drift ±6 µV/ °C
Span drift ±25 ppm /
o
C
CMR @ 50/60 Hz 92 dB
Input impedance 2 MΩ
Watchdog timer Yes
Power requirements +10 to +30 V
DC
(non-regulated)
Power consumption 1.2 W
