Technical specifications
A-26 ADAM 4000 Series User's Manual
A.11 ADAM-4050 Digital I/O Module
Table A-15 ADAM-4050 Specifications
I/ O Channels 7 inputs
8 outputs
Input/Output RS-485 (2-wire)
speed (bps) 1200, 2400, 4800, 9600, 19.2K, 38.4K
maximum distance 4000 ft. (1200 m)
Digital Output 8-channel open collector to 30 V
sink-current 30 mA
power dissipation 300 mW
Digital Input 7-channel
logic level 0 +1 V max.
logic level 1 +3.5 to +30 V
Pull-up current 0.5 mA, 10K resistor to +5 V
Watchdog timer Yes
Power supply +10 to +30 V
DC
(non-regulated)
Power consumption 0.4 W
