A-14 ADAM 4000 Series User's Manual
A.6 ADAM-4016 Strain Gauge Input Module
Table A-8 ADAM-4016 Specifications
Input range ±15 mV, ±50 mV, ±100 mV, ±500 mV and
±20 mA
Output RS-485 (2-wire)
Speed (bps) 1200, 2400, 4800, 9600, 19.2K, 38.4K
Maximum distance 4000 ft. (1200 m)
Isolation voltage 3000 V
DC
Sampling rate 10 samples/sec
Bandwidth 4 Hz
Accuracy ±0.05% or better
Zero drift ±6 µV / °C
Span drift ±25 ppm / °C
CMR @ 50/60 Hz 150 dB
NMR @ 50/60 Hz 100 dB
Analog output range 0~10 V
Drive current 30 mA
Isolation voltage 3000 V
DC
Accuracy 0.05% of FSR
Drift ± 50 ppm/ °C
Input impedance 2 MΩ
Digital output 4 channels open collector to 30 V
sink current 30 mA max. load
power dissipation 300 mW
Watchdog timer Yes
Power requirements +10 to +30 V
DC
(non-regulated)
Power consumption 2.2 W
