B-6 ADAM 4000 Series User's Manual
Data Formats and I/O Ranges
Thermocouple Type
Temperature Range
(Degrees)
Temperature Range
(Hex)
J 0 C to 760 C 0000h - 7FFFh
T -100 C to 400 C E000h - 7FFFh
R 500 C to 1750 C 2492h - 7FFFh
and symmetric about zero is assumed. The following table provides several
examples.
The given span of the specified range is used to determine the RTD input
ranges for twos complement hexadecimal values. As an example, if the
nickel RTD is specified for the range -80
o
C to +100
o
C, the respective values
in hexadecimal notation would be 8000h to 7FFFh.
