Advantech Adam-4012 User Manual

I/O Modules
3-30 ADAM 4000 Series User's Manual
Application Wiring
internal Built 1200hm Resister
ADAM-4017+ 8-ch. differential analog input module wiring diagram
1)Link to http://www.advantech.com
2)Click Support to get in eService Knowledge Center
3)Search for download and key-in “ADAM-4000” to get the latest
ADAM-4000 User’s Manual
11
Vin 0+
Vin 0-
Vin 1+
Vin 1-
mV/V
V
+
-
11
Vin 0+
Vin 0-
Vin 1+
Vin 1-
±
4~20 mA
+
-
