I/O Modules
3-58 ADAM 4000 Series User's Manual
Figure 3-54
Non-isolated Input
Figure 3-55
Photo-isolated Input
Application Wiring
Counter Input
GATE0
IN0
1
D.GND
Gate Control
GND
GATE1+
GATE1-
11
IN1-
IN1+
+
-
+
-
Counter Input
GATE Control
