Advantech Adam-4016 User Manual

Chapter 4 Command Set 4-
97
4018M
Chapter 4
Bit 3 Bit 2 Bit 1 Bit 0
@AARNNNN
Name Read Record Content
Description Request the content of record NNNN stored in the analog input
data logger at address AA.
Syntax @AARNNNN (cr)
@ is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address of an analog input data logger.
R identifies the Read Record Content command.
NNNN represents the 4-character decimal number of stored
record index. Its value is from 0 to (total record number - 1).
(cr) is the terminating character, carriage return (0Dh).
NOTE:
NNNN is from 0 to 9999 for Standard Mode.
NNNN is from 0 to 4599 for Event Mode.
NNNN is from 0 to 7299 for Mixed Mode. (0-4999 are data
records, 5000-7299 are event records)
Response !AACDHHHH(cr) if the returned data are data records.
!AACDHHHHTTTTTTTT(cr) if the returned data are event
records.
! is a delimiter character indicating a valid command was
received.
AA (range 00-FF) represents the 2-character hexadecimal
address of an analog input module.
C represents the channel index. Its value is from 0 to 7.
D represents the 4-bit binary number. Bit 0 represents the sign
of the number HHHH. ‘0’ means positive. ‘1’ means negative.
Bits 1-3 represents the decimal point of the number HHHH.
Decimal point
Sign

Advantech Adam-4016 Specifications

General

Input Channels	16
Analog Input	Yes
Resolution	16-bit
Communication	RS-485
Protocol	Modbus RTU
Isolation Voltage	3000 VDC
Input Type	mV, V, mA
Input Range	0 to 20 mA, 4 to 20 mA
Accuracy	±0.1% of FSR
Sampling Rate	10 samples/second (total)
Power Supply	10 to 30 VDC
Operating Temperature	-10°C ~ +60°C (14°F ~ 140°F)
Storage Temperature	-25 ~ 85 °C (-13 ~ 185 °F)
Humidity	10 ~ 95% RH (non-condensing)
Weight	300 g

Summary

Chapter 1 Introduction

1.1 Overview

Provides a general description of the ADAM Series modules, their features, and power requirements.

Chapter 2 Installation Guideline

2.1 System Requirements to set up an ADAM network

2.2 Basic configuration and hook-up

Explains the default factory settings and the basic procedure for configuring and connecting ADAM modules.

2.3 Baud rate and Checksum

Covers the process of setting the baud rate and enabling/disabling the checksum feature for reliable communication.

Chapter 3 I/O Modules

3.1 ADAM-4011/4011D/4012/4013/4015 Analog Input Modules

Describes the functionality and specifications of various ADAM analog input modules, including thermocouple and RTD types.

3.2 ADAM-4016 Analog Input/Output Module

3.3 ADAM-4017/4017+/4018/4018M/4018+ 8-channel Analog Input Modules

Covers 8-channel analog input modules, including differential and thermocouple types, and data logger functionality.

3.4 ADAM-4019 8-channel Universal Analog Input Module

3.5 ADAM-4021 Analog Output Module

3.6 ADAM-4050/4051/4052/4053/4055 Digital I/O Modules

Describes various ADAM digital I/O modules, including isolated and non-isolated types, and their channel configurations.

3.7 ADAM-4060/4068 Relay Output Module

3.8 ADAM-4080/4080D Counter/Frequency Input Modules

Covers counter and frequency input modules, including programmable digital filters and thresholds for signal processing.

Chapter 4 Command Set

4.2 Syntax

4.3 I/O Module Commands Search Table

Provides a comprehensive table listing commands for different I/O modules, including their syntax and function.

4.4 Analog Input Module Command

Details the command set specific to analog input modules, covering configuration, data reading, and calibration.

4.5 Analog Output Module Command

Outlines the commands for configuring and controlling ADAM analog output modules, including calibration and data output.

4.6 Digital I/O and Relay Output Module Command

Lists commands for controlling digital I/O and relay output modules, covering data input/output and status checks.

4.7 Counter/Frequency Module Command

Details commands for counter and frequency modules, including configuration, setup, and data retrieval.

Chapter 5 Calibration

5.1 Analog Input Module Calibration

Explains the software-based calibration procedures for ADAM analog input modules, including zero and span calibration.

5.2 Analog Input Resistance Calibration

5.3 Analog Output Calibration

Describes the process for calibrating ADAM analog output modules, focusing on setting output values for current and voltage ranges.

Appendix B Data Formats and I/O Ranges

B.1 Analog Input Formats

Explains the different data formats for analog input modules, including Engineering Units, Percent of FSR, and Twos Complement Hexadecimal.

B.2 Analog Input Ranges

B.3 Analog Output Formats
