289 ADAM-4000 Series User Manual
Appendix A Technical Specifications
A.5 ADAM-4016 Analog Input/Output Module
Table A.7: ADAM-4016 Specifications
AI channel number 1
AI range ±15 mV, ±50 mV, ±100 mV, ±500 mV and ±20 mA
Output
Speed (bps)
Maximum distance
RS-485 (2-wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K
4000 ft. (1200 m)
Input impedance Voltage: 2 M, Current: 125
AI isolation voltage
3000 V
DC
AI resolution 16-bit
AI sampling rate 10 samples/second
AI accuracy ±0.05% or better
AI zero drift ±6 V /?
AI span drift ±25 ppm/?
AI CMR @ 50/60 Hz 150 dB
AI NMR @ 50/60 Hz 100 dB
AO channel number 1
AO range 0~10 V
AO drive current 30 mA
AO isolation voltage
3000 V
DC
AO accuracy 0.05% of FSR
AO drift ± 50 ppm/°C
Digital output
Sink current
Power dissipation
4 channels open collector to 30 V
30 mA maximum load
300 mW
Support protocol ADAM ASCII
Watchdog timer 1.6 second (System)
Power requirements
+10 to +30 V
DC
(non-regulated)
Power consumption
2.2 W @ 24 V
DC
To Next Page
