Chapter 3
Chapter 3 I/O Modules
3-9
NOTE: 1. Because the CJC sensor of ADAM-4118 is located in the side of
channel 0 to 4, the measurement will have the difference ± 1
0
C
between channel 0 ~ 4 and channel 5 ~ 7.
2. The ADAM-4118 Input Range Accuracy for Thermocouple is
showed as below
ADAM-4118 Input Range Accuracy for Thermocouple
Input Range Typical
Accuracy
Maximum
Error
Units
J thermocouple
0 to 760 °C
±1.0 ±1.5 °C
K thermocouple
0 to 1370 °C
±1.0 ±1.5 °C
T thermocouple
-100 to 400 °C
±1.0 ±1.5 °C
E thermocouple
0 to 1000 °C
±1.0 ±1.5 °C
R thermocouple
500 to 1750 °C
±1.2 ±2.5 °C
S thermocouple
500 to 1750 °C
±1.2 ±2.5 °C
B thermocouple
500 to 1800 °C
±2.0 ±3.0 °C
