ADAM-4570 Series User Manual 2
Chapter 1 Overview
1.1 Introduction
Advantech's ADAM-4570 series of Industrial Serial Device Servers are a
robust, feature-rich, and cost effective way to network-enable equipment
in an industrial automation environment. ADAM-4571/4570 provide one
or two RS-232/422/485 serial ports, and ADAM-4571L/4570L provide
one or two RS-232 serial ports.
By encapsulating serial data and transporting it over Ethernet, the
ADAM-4570 series allows virtual serial links over Ethernet and IP (TCP/
IP, UDP/IP) networks. After Advantech Serial Device Sever Configura-
tion Utility installation, standard serial operation calls are transparently
redirected to the serial device servers, guaranteeing compatibility with
legacy serial devices and enabling backward compatibility with existing
software.
1.2 Features
• Up to 255 serial ports for one 2000/XP/Vista (x86) host
• Supports 10/100 Mbps auto-sensing Ethernet port
• Supports high transmission speeds up to 921.6 Kbps
• Supports LED indicators: Easy to diagnostic
• Supports integrated configuration utility and port-mapping utility:
easy to configure and manage 255 COM ports and self-diagnostic
• Easy to locate specific ADAM-4570 Device Servers
• Supports multi-access features: allows max. of 5 hosts to access one
serial port simultaneously
• Surge protection for power line
• Mounts on DIN-rail, panel or piggyback easily
