C-2 ADAM-5510/P31
Data Formats and I/O Ranges
C.1 Analog Input Formats
The ADAM analog input modules can be configured to transmit data
to the host in Engineering Units.
Engineering Units
Data can be represented in Engineering Units by setting bits 0 and 1 of
the data format/checksum/integration time parameter to 0.
This format presents data in scientific units, such as degrees, volts,
millivolts, and milliamps. The Engineering Units format is readily
parsed by the majority of computer languages because the total data
string length, including sign, digits and decimal point, does not exceed
seven characters.
The data format is a plus (+) or minus (-) sign, followed by five decimal
digits and a decimal point. The input range which is employed deter-
mines the resolution, or the number of decimal places used, as illustrat-
ed in the following table:
Input Range Resolution
±15 mV, ±50 mV 1 µV (three decimal places)
±100 mV, ±150 mV,
±500 mV
10 µV (two decimal places)
±1 V, ±2.5 V, ±5 V 100 µV (four decimal places)
±10 V 1 mV (three decimal places)
±20 mA 1 µA (three decimal places)
Type J and T
thermocouple
0.01ºC (two decimal places)
Type K, E, R, S, and B
thermocouple
0.1ºC (one decimal place)
