D-24 ADAM-5510/P31
Performance
D.2.3 Connecting 16 AI/O Modules Performance
Since ADAM-5510/P31 Remote I/O function can simultaneously be
connected to a maximum of 16 Analog Input/Output ADAM-4000
modules, you can select among them for performance testing.
The following example illustrates the performance for connecting 16
AI/O modules.
ADAM-4013
ADAM-4017 * 2
ADAM-4018 * 12
ADAM-4021
We configure functional blocks for all channels.
Result
The memory performance: 81,678 byte.
The scanning time: 0.822 second.
D.2.4 Connecting 32 Modules Performance
Since ADAM-5510/P31 Remote I/O function can simultaneously be
connected to a maximum of 32 ADAM-4000 modules(At most 16AI/O
modules), you can select among them for performance testing.
The following example illustrates the performance for connecting 32
modules.
ADAM-4011
ADAM-4012
ADAM-4013 * 3
ADAM-4017 * 2
ADAM-4018 * 15
ADAM-4021
ADAM-4050 * 2
ADAM-4052
ADAM-4053
ADAM-4060 * 2
ADAM-4080 * 3
We configure functional blocks for all channels.
