ADAM-5510/P31 4-3
Chapter 4
Application wiring
Figure 4-2: RTD inputs
EXC0+
SEN0+
SEN0-
EXC0-
A.GND
2 Wire
RTD
EXC0+
SEN0+
SEN0-
EXC0-
A.GND
3 Wire
RTD
EXC0+
SEN0+
SEN0-
EXC0-
A.GND
4 Wire
RTD
