Advantech ADAM-5510/P31 User Manual

ADAM-5510/P31 4-15
Chapter 4
Technical specifications of ADAM-5018
Table 4-6: Technical specifications of ADAM-5018
4.4 Analog Output Modules
ADAM-5024 4-channel analog output module
The ADAM-5024 is a 4-channel analog output module. It receives its
digital input from the host computer, via the RS-485 interface of the
ADAM-5510/P31 main unit. The format of the data is engineering
units. It then uses the D/A converter controlled by the main unit to
convert the digital data into output signals.
Analog Input Channels Seven differential
Input Type mV, V, mA, Thermocouple
Input Range ± 15 mV, ± 50 mV,
± 100 mV, ± 500 mV, ± 1 V,
± 2.5 V and ± 20 mA
T/C Type and
Temperature Range
J 0 to 760 °C
K 0 to 1370 °C
T -100 to 400 °C
E 0 to 1400 °C
R 500 to 1750 °C
S 500 to 1750 °C
B 500 to 1800 °C
Isolation Voltage 3000 V
DC
Sampling Rate 10 samples/sec (total)
Input Impedance 2 Mohms
Bandwidth 13.1 Hz @ 50 Hz, 15.72 Hz
@ 60 Hz
Accuracy ± 0.1% or better
Zero Drift ± 0.3 µV/°C
Span Drift ± 25 PPM/°C
CMR @ 50/60 Hz 92 dB min.
Power Consumption 1.2 W
