4-14 ADAM-5510/P31
I/O Modules
ADAM-5018
Figure 4-10: ADAM-5018 module frontal view
Application wiring
Figure 4-11: Thermocouple input
16
1
ADAM-5018
7 T/C
V3-
V3+
V2-
V2+
V1-
V1+
V0-
V0+
V4+
V4-
V5+
V5-
V6+
V6-
CJC+
CJC-
V1-
V1+
V0-
V0+
1
+
-
T/C
