ADAM-5510/P31 4-25
Chapter 4
Figure 4-19: Dip switch setting for digital I/O channel
ADAM-5050
Figure 4-20: ADAM-5050 module frontal view
Application wiring
Figure 4-21: Dry contact signal input (ADAM-5050)
Dip Switch Key
ON = Digital Output
OFF = Digital Input
CH0 CH15
16
1
ADAM-5050
16 UDIO
V15
V14
V13
V12
V11
V10
V9
V8
V0
V1
V2
V3
V4
V5
V6
V7
