3 ARK-1550 User Manual
Chapter 1 General Introduction
1.3 Hardware Specification
CPU: Intel® 4th generation DC Core i5 4300U 1.91GHz / DC Celeron 2980U
1.66 GHz
System Chipset: Intel® HD Graphics 4400
BIOS: AMI EFI 128 Mbit
System Memory: 1 x 204-pin SO-DIMM DDR3L 1333/1600 MHz, support up to
8GB
Display:
– VGA: Up to 1920 x 1200 at 60 Hz
– HDMI: Up to 4096 x 2304 at 24 Hz
– LVDS (optional by T-PN): Up to 1920 x 1200 at 60 Hz
Storage:
– 1 x hot swappable 2.5" SATA HDD (maximum height: 9.5 mm)
– 1 x Full size mSATA
Watchdog Timer: 255-level timer interval, setup by software
I/O Interface:
– COM: 1 x RS-232, 2 x RS-232/422/485 (BIOS selectable)
– USB: 2 x USB 2.0, 2 x USB 3.0
– LAN1: Intel I218 GbE, support wake on LAN
– LAN2: Intel I210 GbE, support wake on LAN
– DIO: 8-bit DIO
– Audio: Realtek ALC888S, High Definition Audio. Line-out, Mic-in, Line-in
Expansion:
– 1 x Full-size Mini PCIe slot w/ SIM holder, support mSATA storage or WWAN
module
– 1 x Half-size Mini PCIe slot, support WLAN module
